28 About Your Computer
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air
vents. Do not store your computer in a low-airflow environment, such as a closed
briefcase, while it is running. Restricting the airflow can damage the computer or
cause a fire.
AIR VENTS — The computer uses an internal fan to create airflow through the vents,
which prevents the computer from overheating. The computer turns the fan on when
the computer gets hot. Fan noise is normal and does not indicate a problem with the
fan or the computer.
1 off Disables wireless devices.
2 on Enables wireless devices.
3 momentary Scans for WLAN networks (see "Dell Wi-Fi
Catcher™ Network Locator" on page 107).
4 Dell Wi-Fi Catcher Network
Locator light
• Flashing green: Searching for networks
• Solid green: Strong network found
• Solid yellow: Weak network found
• Flashing yellow: Error
• Off: No signal found
NOTE: The Wi-Fi Catcher Network Locator light
appears only when the computer is turned off and
the wireless switch is configured in the system
setup program (BIOS) to control WiFi network
connections.
1 2 3 4
