Adding and Replacing Parts 167
Returning a Hard Drive to Dell
Return your old hard drive to Dell in its original, or comparable, foam
packaging. Otherwise, the hard drive may be damaged in transit.
Optical Drive
CAUTION: Before you begin any of the procedures in this section, follow the
safety instructions in the Product Information Guide.
Removing the Optical Drive
1
Follow the procedures in "Before You Begin" on page 161.
2
Turn the computer over.
3
Remove the device security screw from the optical drive.
4
Using a plastic scribe, push the notch to release the optical drive from the
bay.
5
Slide the optical drive out of the bay.
1 foam packaging 2 hard drive
2
1
book.book Page 167 Tuesday, September 8, 2009 2:01 PM
