Figure 12 details the dimensions of the Dell™ PowerEdge™ T320 chassis.

with

bezel

without

bezel

218.0mm

304.5mm (foot)

307.9mm (caster)

430.3mm

443.3mm

471.3mm

16.4mm

0.0mm

542.2mm

578.42mm

Zb goes to the nominal back wall external surface where the I/O connectors reside.

The maximum system weight for the T320 is 29.55kg (65lb).

Table 25 lists power supply specifications for the PowerEdge T320.

Specification

Redundant 750W

Redundant 495W

Non-redundant 350W

Current consumption

10A–5A

6.5A–3A

4.8A-2.4A

Supply voltage

100–240VAC

Frequency

50/60Hz

Heat dissipation (BTU/hr max)

2891

1908

1456
